HOW TO USE YOUR RIVET TOOL
3
BACK TO
INDEX
Select rivet with grip range larger than
thickness of materials to be fastened.
drill hole same size as rivet diameter.
Select correct size nosepiece in accordance with rivet
diameter. open tool handles and
insert rivet.
Place rivet in hole. squeeze handle to
pull & cut off excess mandrel.
When changing a nose piece, depress the handles.
Then unscrew the nosepiece with wrench.
Caution: If you do not depress the handles, the opened
nose could jump off quickly.
The RH200™
Uses 4 Sizes of Rivets
3/32”(2mm) 1/8”(3mm)
5/32”(4mm) 3/16”(5mm)
