ANCHORING OPTIONS...
The entire fl oor frame MUST be securely anchored once the building is erected.
Below are recommended ways of anchoring.
Anchoring Down The Building
Anchoring into Concrete:
1. For poured concrete slab or footing or patio blocks:
Use 1/4" x 2" (6 mm x 51 mm) Lag Screws.
2. For Anchor Post of Concrete poured after building is
erected: Use 1/4" x 6" (6 mm x 152 mm) Lag Screws.
Anchoring into Wood/Post:
Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm)
dia. holes provided in the frames for proper anchoring.
1.
2.
1. 2.
IMPORTANT:
31EE
• If you have swing doors, they must hang and swing level before anchoring building.
• Anchor your building at this time. See below for details on anchoring.
• Please take a moment to ensure that the building is installed in accordance
with these instructions and with all applicable regulations.
