OPERATING I
NSTRUCTIONS
TO LOAD
1. Remove pusher rod from machine.
2. Insert strip of staples.
3. Replace pusher rod.
STAPLE PENETRATION
For best penetration with any gun tacker, raise the
rear
of the gun slightly off the work and bear down
on the front end to prevent recoil when operating.
The power spring on the T59 will drive well into
all ordinary woods.
T59
™
1/4" x 1/4"
6mm x 6mm
1/4" x 5/16"
6mm x 8mm
5/16" x 5/16"
8mm x 8mm
TO CLEAN STAPLE CHANNEL
1. Remove pusher rod A.
2. Remove screw and nut from hole B.
3. Pull down entire inside frame for complete cleaning.
How to determine staple shortage for rell.
1. Press latch to release pusher rod.
2. Lightly push rod forward until it stops. Visible projected part of rod indicates amount
of staples remaining in track.
