The splice posts support the walls.
1 Position splice post at the center
of the rear wall and fasten using 4
screws into rear wall angle and 2
screws into rear floor frame.
Hint: Measure or count holes to de-
termine if post is centered on angle.
2 Fasten splice posts to the sides of
building in the same manner.
● ●
● ●
● 5287 Splice Post (3)
● Parts Needed For ●
Splice Post
Step 8
SX21
21
STEP
2
5287
FRONT
STEP
1
5287
5287
To Next Page
