KNOB
The Knob allows you to externally control the rotation of the internal reel. Before you insert the knob
in place you must always make sure that the internal cylinder is clean not to damage the gasket. The
Knob can only be inserted in and out by aligning the small symbol with the one on the tank.
CRANK (accessory)
The Crank accessory eases the external control of the internal reel. It consists of two pieces: a xed
one and a movable one. Once you have inserted the disc aligning the plastic line with the symbol on
the tank, turn the disc by 90 degrees to keep it locked. To uninsert the Crank, realign the line with the
symbol and pull outwards. Before you use the Crank, check that the internal cylinder is clean in order
not to cause damage to the gasket.
| Contents - KNOB & CRANK |
Insert the crank into the tank hole.
Turn the crank base by 90° until locked.
Match the point on the tank with the point on the knob to insert and remove it
