Art Quadra/FX - Page 33

- 30 -
Bass Control
-20
-15
-10
-5
0
5
10
15
20
10 100 1000 10000
Frequency in Hz (Log Scale)
Boost (dB)
High EQ
Each effect has a user adjustable high equalization control that is inline with the processed (wet) signal. It has a
variable slope with a maximum treble boost/cut amount of ±15 dB (in 1-dB steps).
Treble Control
-20
-15
-10
-5
0
5
10
15
20
100 1000 10000 100000
Frequency in Hz (Log Scale)
Boost (dB)
