Artemis Cine - Page 25

artemis Gomponents
manual
Lower Sled
Camera
/ Monitor
Battery
\
\
/a'
//'
Battery Gombinations
As
pointed
out above,
always two batteries
must be mounted.
There are
following combinations:
.
Mon-Cam
Battery
plus
Camera-Battery
.
Camera-Battery
plus
C-Battery
.
Mon-Cam Battery
plus
Camera-Battery
plus
C-Battery
Camera
Battery
"C"-Battery
Combination
for
12
Volt Mode
Using
a CRT Green
hlonitor
|n this сase two batteries
are used on the
pivoting
battery
mount.
In mon/cam
position,
the upper battery supplies
on|y the
video
сirсuit, suсh
as
monitor, video
transmitter, etс.,
with 12
VDс.
In cаmera
position,
the battery at the bottom supp|ies
on|y the сamera сirсuit,
i' e' сamera,
foсus remote
and
"aux
powe/'outputs,
with 12
VDC.
..с''-вattery
on/off Switсh
Switches:
Тhe seleоtor switсhes
for
C-Battery
must be set
on
"OFF
and the
vo|tage seleсtor
at the front
of the sled
must be
set
on
"12
Volt".
sg
@
^пhv.
BOr
@
12Yo|tl24Yo|| Switсh
23
