A
C
B
D
E
x2 M6 Barrel Nuts
x2 M6x55 Bolt Screws
x2 Screw Caps
x4 M5x25 Hand Bolts
x4 M4x25 Bolt Screws
Left and Right Legs
Crosspiece
Piano
Pedal Board
3-Pedal
A
A
C
A
C
B
Assembling Your Furniture Stand
What’s Included
1. Assembling the Pedal Board.
Begin assembling the piano by attaching
the 3-pedal mechanism to the pedal board.
Step 1
Begin by instering two barrel nuts (A)
into the pedal crosspiece board, as shown.
Step 2
Put the barrel nut into the pedal board
as shown, make sure it is in the proper position
to receive the inserted screw. Please make sure
to properly fasten the bolt through the pedal board
and into the barrel nut.
