Artusi ABBQ1B - Assembling the Barbecue

12
Rev.13052022
TOOLS NEEDED FOR ASSEMBLY:
- Phillips screwdriver
1. Remove all components from the box.
2. Place the ame diffusers in the desired positions (under the points (A) in which the grill sections will be placed) and attach
the rear edge of the ame diffuser to the rear of the body of the barbecue.
ASSEMBLING THE BARBECUE
BACK
BACK
FRONT
FRONT
