Gree GMV6 DC Inverter VRF Units Service Manual
60
removal mode.
LED1 LED2 LED3
Function code
Display status
Current process
Display status
Current status
Display status
5L On 00 Blinks OC Blinks
5L
On
01
Blinks
OC
Blinks
5L On 02 Blinks OC Blinks
After selecting the corresponding value, press the SW3 confirm button. The master module displays
as follows:
LED1
LED2
LED3
Function code
Display status
Mode
Display status
Current status
Display status
5L
On
00
On
OC
On
5L
On
01
On
OC
On
5L
On
02
On
OC
On
The master unit memorizes this setting and does not clear it even upon power failure and power-on
again. The default value is 00. Mode 00 indicates the fan reverse dust removal function is turned off, 01
indicates fan reverse dust removal mode 1, and 02 indicates mode 2.
4.2.3.20 5n Fan Anti-Snow
Setting steps:
Enter the function setting. The master unit displays as follows by default, and other basic modules
display normal working status:
LED1
LED2
LED3
Function code
Display status
Current process
Display status
Current status
Display status
5n
On
00
Blinks
OC
Blinks
Press the SW1 up button and the SW2 down button to select the corresponding fan anti-snow
mode.
LED1 LED2 LED3
Function code
Display status
Current process
Display status
Current status
Display status
5n
On
00
Blinks
OC
Blinks
5n
On
01
Blinks
OC
Blinks
After selecting the corresponding value, press the SW3 confirm button. The master module displays
as follows:
LED1
LED2
LED3
Function code
Display status
Mode
Display status
Current status
Display status
5n
On
00
On
OC
On
5n
On
01
On
OC
On
The master unit memorizes this setting and does not clear it even upon power failure and power-on
again. The default value is 00. Mode 00 indicates that this function is off, and 01 indicates that this
function is on.
