Gree GMV6 DC Inverter VRF Units Service Manual
7
Model
-
GMV-1845WM/H-X
GMV-1905WM/H-X
GMV-1959WM/H-X
GMV-2015WM/H-X
HP
HP
66
68
70
72
Combination mode
- 22+22+22 10+16+20+22 10+18+20+22 10+20+20+22
-
GMV-615WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X
GMV-280WM/H-X+
GMV-450WM/H-X+
GMV-560WM/H-X+
GMV-615WM/H-X
GMV-280WM/H-X+
GMV-504WM/H-X+
GMV-560WM/H-X+
GMV-615WM/H-X
GMV-280WM/H-X+
GMV-560WM/H-X+
GMV-560WM/H-X+
GMV-615WM/H-X
Cooling
capacity
Rated kW 184.5 190.5 195.9 201.5
Heating
capacity
Rated kW 99 103.52 111.2 111.2
Max.
kW
207
213.5
220
226.5
Outdoor static
pressure
Pa 0-110 0-110 0-110 0-110
Power Supply
-
380-415V 3N~ 50/60Hz
380-415V 3N~ 50/60Hz
380-415V 3N~ 50/60Hz
380-415V 3N~ 50/60Hz
Rated power input kW 27.41+27.41+27.41 13.15+22.00+26.85+27.41 13.15+26.30+26.85+27.41 13.15+26.85+26.85+27.41
Rated current
A
49+49+49
23.5+39.3+48+49
23.5+47+48+49
23.5+48+48+49
Cooling operation
range
°C -5~55 -5~55 -5~55 -5~55
Heating operation
range
°C -30~24 -30~24 -30~24 -30~24
Refrigerant type
-
R410A
R410A
R410A
R410A
Refrigerant charge
kg
24.9
29.6
30.4
30.4
Maximum drive
IDU NO.
unit 80 80 80 80
Gas pipe mm Φ41.3 Φ44.5 Φ44.5 Φ44.5
Liquid pipe
mm
Φ19.05
Φ22.2
Φ22.2
Φ22.2
Outline dimensions
(W × D × H)
mm
1340×775×1690+
1340×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
Packing
dimensions
(W × D × H)
mm
1400×830×1855+
1400×830×1855+
1400×830×1855
1000×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1000×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1000×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
Net weight
kg
1065
1225
1275
1275
Gross weight kg 1110 1280 1330 1330
Model
-
GMV-2070WM/H-X
GMV-2125WM/H-X
GMV-2180WM/H-X
GMV-2245WM/H-X
HP HP 74 76 78 80
Combination mode
-
10+20+22+22
10+22+22+22
12+22+22+22
14+22+22+22
-
GMV-280WM/H-X+
GMV-560WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X
GMV-280WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X
GMV-335WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X
GMV-400WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X
Cooling
capacity
Rated kW 207 212.5 218 224.5
Heating
capacity
Rated
kW
113.2
115.2
117.5
122.32
Max.
kW
232.5
238.5
244.5
252
Outdoor static
pressure
Pa 0-110 0-110 0-110 0-110
Power Supply - 380-415V 3N~ 50/60Hz 380-415V 3N~ 50/60Hz 380-415V 3N~ 50/60Hz 380-415V 3N~ 50/60Hz
Rated power input kW 13.15+26.85+27.41+27.41 13.15+27.41+27.41+27.41 13.50+27.41+27.41+27.41 21.00+27.41+27.41+27.41
Rated current
A
23.5+48+49+49
23.5+49+49+49
24.1+49+49+49
37.5+49+49+49
Cooling operation
range
°C -5~55 -5~55 -5~55 -5~55
Heating operation
range
°C -30~24 -30~24 -30~24 -30~24
Refrigerant type
-
R410A
R410A
R410A
R410A
Refrigerant charge
kg
30.4
30.4
32.4
32.4
Maximum drive IDU
NO.
unit 80 80 80 80
Gas pipe
mm
Φ44.5
Φ44.5
Φ44.5
Φ44.5
Liquid pipe mm Φ22.2 Φ22.2 Φ22.2 Φ22.2
