Gree GMV6 DC Inverter VRF Units Service Manual
8
Model
-
GMV-2070WM/H-X
GMV-2125WM/H-X
GMV-2180WM/H-X
GMV-2245WM/H-X
Outline dimensions
(W × D × H)
mm
930×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
930×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
Packing
dimensions
(W × D × H)
mm
1000×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1000×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1000×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
Net weight
kg
1280
1285
1305
1365
Gross weight
kg
1335
1340
1360
1425
Model
-
GMV-2295WM/H-X
GMV-2349WM/H-X
GMV-2405WM/H-X
GMV-2460WM/H-X
HP HP 82 84 86 88
Combination mode
-
16+22+22+22
18+22+22+22
20+22+22+22
22+22+22+22
-
GMV-450WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X
GMV-504WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X
GMV-560WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X
GMV-615WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X+
GMV-615WM/H-X
Cooling
capacity
Rated kW 229.5 234.9 204.5 246
Heating
capacity
Rated kW 122.32 130 130 132
Max.
kW
257
263.5
270
276
Outdoor static
pressure
Pa 0-110 0-110 0-110 0-110
Power Supply
-
380-415V 3N~ 50/60Hz
380-415V 3N~ 50/60Hz
380-415V 3N~ 50/60Hz
380-415V 3N~ 50/60Hz
Rated power input kW 22.00+27.41+27.41+27.41 26.30+27.41+27.41+27.41 26.85+27.41+27.41+27.41 27.41+27.41+27.41+27.41
Rated current A 39.3+49+49+49 47+49+49+49 48+49+49+49 49+49+49+49
Cooling operation
range
°C -5~55 -5~55 -5~55 -5~55
Heating operation
range
°C -30~24 -30~24 -30~24 -30~24
Refrigerant type
-
R410A
R410A
R410A
R410A
Refrigerant charge
kg
32.4
33.2
33.2
33.2
Maximum drive IDU
NO.
unit 80 80 80 80
Gas pipe mm Φ44.5 Φ44.5 Φ44.5 Φ44.5
Liquid pipe
mm
Φ22.2
Φ22.2
Φ22.2
Φ22.2
Outline dimensions
(W × D × H)
mm
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
1340×775×1690+
1340×775×1690+
1340×775×1690+
1340×775×1690
Packing
dimensions
(W × D × H)
mm
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
Net weight
kg
1365
1415
1415
1420
Gross weight kg 1425 1475 1475 1480
Note:
① Rated cooling capacity test conditions: indoor 27℃ DB/19 ℃ WB, outdoor 35℃ DB;
connection pipe length: 5 m, without height drop between units.
② Rated heating capacity test conditions(Tdesingnh): indoor 20℃ DB, outdoor -10℃ DB/-11 ℃
WB; connection pipe length: 5 m, without height drop between units. Max heating capacity
test conditions: indoor 20℃ DB, outdoor 7℃ DB/6 ℃ WB; connection pipe length: 5 m,
without height drop between units.
③ The total capacity of connected indoor units must be in the range of 50%~135% of the outdoor
unit capacity. The relevant parameters can be corrected by referring to the unit capacity
correction table.
