!!!!!!A-Frame Ladder
• To configure the Mighty Multi into the A-Frame (Step Ladder
position) follow instructions for adjusting the Hinge Lock on page
7.
• After placing the ladder into the Step Ladder configuration, you
may then adjust the height of the Step Ladder by utilizing the J-
Locks
(see page 8).
• Check that all locks are securely seated into
the locked position before attempting to
climb.
• Always face ladder while on it and maintain a
good grip on the rails while working and
climbing.
• Never stand on or above the second rung from
the top, regardless of proximity to the ground.
Extension Ladder
• To configure the Mighty Multi to the Extended position,
begin by unlocking the Hinge Locks and straightening the
ladder (see page 7).
• The ladder may then be lengthened by unlocking the J-Locks
(see page 8) and sliding the OUTER SECTION to the desired
length.
• When positioning the Extension Ladder, the angle to the vertical
plane of support should be 75 degrees (see Diagram 1).
