TD 90227GB
10 October 2013 / Ver. D
System Installation
Ascom Paging System
14
8 Current Consumption
When calculating total current load always use the max consumption for each unit. Linear
power supplies are generally recommended, specially for the transmitters, line equipment,
and at locations with strong electromagnetic fields.
8.1 Central Equipment and Interfaces
Model type Max load (A)
T942C 1.0
T941AM8 0.3
T941AM32 0.3
P940AI 0.5
T941OM 0.5
a
/2.0
b
8.2 Fixed Transmitters
Model type Max load (A)
H952T 2.0
U952T 2.5
8.3 Receiver Equipment
Model type Max load (A)
T981RI 0.3
U982 0.3
U981 0.0.6-0.2
8.4 Line Equipment
Model type Max load (A)
T938D 0.4
T938S 0.15
T938RM 0.1
T938BC2
0.25
a.All outputs are supplied externally.
b.All outputs are supplied internally.
