18
4 - Operation
Over range Under range
Alarm acknowledge
Entry key for selection and value setting confirmation
Menu access
Min and Max. values display
Alarm status LEDs (reds)
Å AL1 ON
Ç AL2 ON
88888_____ 88888
Input value [1]
In engineering uits
-----
Note:
[1] The colour of the dislplay is set through field m of the
Configuration Code (page 17).
4.1.1 KEY FUNCTIONS AND DISPLAY IN OPERATOR MODE
4 OPERATIONS
J1 EN-ed3 17-02-2009 15:05 Pagina 18
