27
4 - Operations
Engineering
units
This parameter allows the user
to view the process in the desi-
red engineering unit. When the
instrument senses temperatu-
re, this parameter allows the
convertion between Farenheit
(°F) and centigrade (°C). All the
engineering units available are
listed at page 23 table 2.
LINEAR SCALE
PARAMETERS
The parameters that follow are-
displayed only when, during the
configuration phase, a linear
input has been selected for IN1
(fileds i and l at page 16).
#Unit
IN1 Input number
of decimals
IN1 input low
range
IN1 input high
range
These parameters allow the user
to set the operating range and
the number of decimal point to
be displayed for the primary (IN1)
input.
IN1 measure
square root
This parameter enables the cal-
culation of the square root of the
IN1 measure (sqrt = enabled,
none = disabled)
Cut-off square
root result
This parameter allows the user
to round to zero those results
that are not meaningful.
Setting range: 0...9999.
Default value: 0.
#CUt 1
#in1.Cn
#in.1Hi
#in.1lo
#in.1dd
SERIAL COMMUNICATIONS
PARAMETERS (OPTIONAL)
The parameters that follow are
displayed only when the optio-
nal communications board is
installed in the instrument.
Comunications
protocol
Baud rate
Instrument
serial address
Values:
Protocol: Modbus/Jbus.
Baud rate:
200/2400/4800/9600 baud.
Instrument serial address:
1...247
Default values:
Protocol: Jbus.
Baud rate: 9600 baud.
Instrument serial address: 1
#Addr
#baud
#prot
SAFETY PARAMETERS
Access code
This parameter allows the user
to change the factory default
password (Code = 33).
If Code is set to 0 (zero), the
access to the instrument is
opern (no password needed).
If 0 < Code ≤ 5000 only the
Conf menu is protected.
Codes higher than 5000
(5000 ≤ Code < 10000), protect
all the 2 main menus of the
instrument.
#Code
