1- Installation
1 INSTALLATION
Installation must only be carried out by
qualified personnel.
Before proceeding with the installation of this
indicator follow the instructions illustrated in
this manual with particular attention to the
installation precautions marked with the
B symbol, related to the European
Community directive on electrical protection
and electromagnetic compatibility.
B
To prevent hands or metal touching parts
that may be electrically live, the indicators
must be installed in an enclosure.
IP 20 Terminal block
EN61010 - 1
(IEC1010 - 1)
Product code label
Sealing front panel gasket
Mounting clamps
Front panel
IP65 protection
EN 650529 (IEC 529)
Panel
surface
1.1 GENERAL DESCRIPTION
