ASENWARE AW-FTP2008 - Order Information

Fire Telephone Panel User Manual 5 / 6
indicator light for manual erasure state, illuminated light bar moves to the right from the
current position. When moving to the right, if they continue to wipe tone, will start from the
beginning. Click the "play" button, the playback indicator light, lit light bar moves from the
current position to the right (i.e, manual playback). In the recording, playback process, you
can press at any time click the "Stop" key to end the operation.
Press the "fast forward" or "rewind" button, the corresponding indicator light, perform the
appropriate action, with a normal recorder operation as easy.
7 Order information
Product photo
Product Information
Name :
Fire Telephone Panel
Model NO.:
AW-FTP2008
Characters:
1. Panel Capacity: 8 zones;
2. Operation Voltage: 24VDC±10%, 220VAC;
3. Environment Temperature: 0~40°C;
4. Relative Humidity: 40%~85%;
5. Dimension: 385mm × 330mm × 120mm;
6. Gross Weight: 4.15kg.
Name :
Fire Telephone Panel
Model NO.:
AW-FTP2016
Characters:
1. Panel Capacity: 16zones;
2. Operation Voltage: 24VDC±10%, 220VAC;
3. Environment Temperature: 0~40°C;
4. Relative Humidity: 40%~85%;
5. Dimension: 385mm × 330mm × 120mm;
6. Gross Weight: 4.15kg.
Name :
Fire Telephone Speaker
Model NO.:
AW-FTS2008
Parameter:
1. Compatiable with Fire Telephone Panel;
2. Operating Voltage: AC220V 50HZ OR DC24V;
3. Alarm Current: ≤0.5A;
4. Temperature Range: 0℃~+40℃;
5. Humidity Range: 40%~85%RH NO VIBRATION;
6. Dimension: 90mm * 55 mm *35mm.
