EC95 19
NOTICE: Parts marked with a
are for the black model BEC95
N/S = NOT SHOWN
KEY PART NO. DESCRIPTION QTY.
1 69228B INNER UNIT ASSEMBLY 1
2 88094 GASKET 1
3 24819 FLUE COLLAR 1
4 40381 REAR BRICK RETAINER 1
5 40132 SIDE BRICK RETAINER 2
6 89066 CERAMIC BRICK (FBP6 PACK OF 6 BRICK) 13
7 24846 SMOKE CURTAIN ROD 1
8 24835 SMOKE CURTAIN ASSEMBLY 1
9 DGK3 FEED & ASH DOOR GASKET KIT 1
10 83485 DOOR PIN 4
11 24837 HINGE KIT FOR FEED DOOR 1
12 24824 RADIATION SHIELD KIT 1
13 89930 HANDLE KIT 2
14 24838 HINGE KIT FOR ASH DOOR 1
15 69230 ASH DOOR ASSEMBLY 1
16 25048 ASH DOOR LATCH (short) 2
17 -------- REFER TO ITEM 9
18 69229 FEED DOOR ASSEMBLY 1
19 25048 FEED DOOR LATCH 1
20 40412 FRONT LINER 1
22 24870 DOOR SHIELD 1
23 69206 ASH PAN WELDMENT 1
24 40394 GRATE 2
25 69205 GRATE SUPPORT ANGLE 2
26 83479 LEVELER (not applicable in newer units) 4
27 88090 MANIFOLD GASKET 1
28 24812 MANIFOLD ASSEMBLY 1
29 69207B DRAFT PLATE ASSEMBLY 1
30 83478 ACORN NUT (NLA) 2
31 24816 INLET COVER PIN (NLA) 1
32-33 24850 CHAIN & "S" HOOK ASSEMBLY 1
34 69532 THERMOSTAT ASSEMBLY 1
45
89142 KNOB
1
89687 KNOB (BLACK)
46
851397 CONTROL PLATE
1
851728 CONTROL PLATE
(BLACK)
47 24849 ROD & NUT KIT 1
48 69224GO TRIM AND SCREEN ASSEMBLY 1
49 24851 LEFT & RIGHT TOP BRACE 2
50 24824 RADIATION SHIELD KIT 1
51
69221TX LEFT SIDE CABINET ASSEMBLY
1
69221B LEFT SIDE CABINET ASSEMBLY
(BLACK)
52
69202TX CABINET TOP ASSEMBLY
1
69202B CABINET TOP ASSEMBLY
(BLACK)
53
89925 CABINET TOP HANDLE KIT
1
891591 CABINET TOP HANDLE KIT
(BLACK)
54
69203TX PANEL BACK ASSEMBLY
1
25597B PANEL BACK
(BLACK)
55
69220TX RIGHT SIDE CABINET ASSEMBLY
1
69220B RIGHT SIDE CABINET ASSEMBLY
(BLACK)
56
69219TX CABINET DOOR ASSEMBLY
1
69219B CABINET DOOR ASSEMBLY
(BLACK)
57 24893 LATCH 1
N/S
89928 HANDLE KNOB, CABINET
1
891592 HANDLE KNOB, CABINET
(BLACK)
58
25551TX TOP FRONT PANEL
1
25551B TOP FRONT PANEL
(BLACK)
N/S 83274 HANDLE NUTS 2
N/S 83045 HANDLE WASHER 1
N/S 83227 BOLTS (Flue Collar) 8
N/S 83250 NUTS (Flue Collar) 8
SEE FIGURE 12 FOR ILLUSTRATION OF PARTS
