Page - 10 Operator Manual – CLX-52 Compressor/Limiter
Copyright© 2011 – Ashly Audio Inc.
Specifications
Specification
CLX-52
Gain
±15dB
Ratio
2.1 to ∞
Attack Time
200µS to 20mS
Release Time
100mS to 3 Sec
Output
-∞ to +18dB
Maximum Input Level
+23dBu
Maximum Output Level
+23dBu
Input Impedance
20KΩ Balanced
Output Impedance
132Ω Servo-Balanced
Frequency Response
20Hz – 20KHz ±0.2dB
Distortion
<.01% THD, 0dBu, 1KHz
<0.15% THD, +15dBu, 20Hz – 20KHz
Output Hum & Noise
-96dBu
Power Requirements
100-240 Volts AC, 50-60Hz, 30 watts
Shipping Weight
8 lbs (3.63kg)
Dimensions
19”L x 1.72”H x 8”D
(483mm x 43.7mm x 203mm)
Note: 0dBu = 0.775 Vrms
Introduction - 4
GQX Equalizers – 5
Connectors & Cables – 5
Physical Description - 6
Installation – 7
Typical Applications - 8
Troubleshooting - 9
Dimensions - 9
Specifications - 10
Warranty - 11
