Rev 3 Page 94
–
QUESTIONS:
1. Is there a gage alias in an available gage suite that will work with your gage?
a. If not, create the gage alias and/or gage suite.
2. Are the labels and choice lists you want to use created?
a. If not, create the desired labels and choice lists.
3. Are there appropriate cause and corrective lists available?
a. If not, create the desired lists in the Choice List Editor.
4. Are your default settings in Preferences and Labels set correctly?
a. If not, configure them as desired.
5. Are the descriptors and choices you need available?
a. If not, create them in the Descriptors Editor
6. Did you save your changes?
SETUP CREATION:
1. Did you name the setup?
2. Did you add a description?
3. Did you assign a gage suite?
4. Is the setup listed as active?
5. Did you add labels to the setup?
6. Did you place them in the correct tab (subgroup, piece or characteristic)?
7. Did you configure the label properties?
8. Did you create variable characteristics?
a. Does each characteristic have the correct name?
b. Does it have a valid description?
c. Is the subgroup size properly configured?
d. Is the source correct?
i. If using a gage, did you identify an alias from the assigned gage suite?
ii. If using operator symbols, Boolean operators or function operators is the syntax
correct?
iii. Is the order of operations correct?
e. Is the resolution configured correctly?
f. Did you reset the limit type if using deviation?
g. Are the target and upper/lower spec limits correct?
h. Did you add reasonable limits and are they valid?
i. Did you define the path for image files if necessary?
j. Did you assign characteristic descriptors?
k. Did you configure Characteristic Events?
9. Did you save the setup?
SETUP GROUP:
1. Did you open or create a setup group?
2. Did you add your new setup to the group?
3. Did you save your changes to the setup group?
