Asko D3122 Use And Care Guide

31
Screw the dishwasher into place
The enclosed plastic plugs are used for cover-
ing the screw holes if the dishwasher is to be
screwed at the sides. After fixing check that the
front feet are in contact with the floor.
Fitting strip seal
(on floor plinth covering plate)
Proceed as follows:
1. Remove the plastic plinth by gripping with
both hands under the plastic plinth (A), and lift
outwards and upwards.
2. Undo the two screws on the covering plate
(B).
3. Glue the accompanying rubber strip (C) to
the underside of the covering plate (against the
floor).
4. Screw the covering plate back into place.
Adjust the covering plate so that the rubber strip
is just in contact with the floor.
5. Replace the plastic plinth
Slide the dishwasher into place
• Pull the drainage hose and connection
pipe when the machine is pushed into
place.
• Check that the hose has no kinks or sharp
bends, and check that there is nothing that
can damage the hoses.
Installing the plinth (kick plate)
The dishwasher has two kick-plates (some
models). The taller one should be used if the
machine is to be 850 - 870 mm high and the
depth of the plinth can be varied between 45 -
105 mm. The lower one is to be used if the
machine will be 820 - 845 mm with a plinth depth
of between 50 - 105 mm. Attach the enclosed felt
insulation to the kick-plate (some models).
Set the correct plinth depth as follows:
1. Bring the grey hooks towards each other and
pull out the brackets
as far as required.
Press in the catches
so that they lock the
brackets in place.
2. Suspend the kick-
plate from the
brackets by pushing
into the slots.
A
B
x
x
x
C
Not all models

Asko D3122 Specifications

General

Type	Freestanding
Energy Star Certified	Yes
Number of Wash Programs	7
Installation	Freestanding
Delay Start	Yes
Child Lock	Yes
