50 51
Technical specifications
TUMBLE DRYERS
T712C
MODEL
Free standing/stacked/built in •/•/•
Door opens R/L= right or left r/l
Color wh/ti
DIMENSIONS
Height mm 850
Width/depth mm 595
Depth with door open mm 1170
Height adjustment mm 30
Weight. kg 47
USER INTERFACE
Knob •
Microprocessor controll micro
Display •
DRYING PROGRAMS
Auto Extra dry •
Auto Dry •
Auto Normal dry •
Auto Iron dry •
Time program mins 60
Air fluff program mins 60
DRYING OPTIONS
Anti-crease program mins 120
Temperature option: low/normal •
Cooling: normal/express -
Buzzer •
Delayed start h1-24
Internal light -
OPERATING DATA
1)
Capacity kg 6
Energy Rating
2)
stars 2
TECHNICAL DATA
Stainless steel drum •
Rated voltage V 230
Frequency Hz 50
Electrical cord, length mm 2100
Drain hose length mm 2000
WARRANTY
2 year comprehensive parts & labour warranty on all models • •
• Standard
1) Based on standard test on 6 kg.
2) Which normally dries using a dryer 150 kg ”dry cotton”, 280 kg ”dry iron”, 150 kg ”easy care”
In compliance with EN, IEC, EMC standards. CE Marked
NB: Dryers: Norm EN 61 121. Electric dryer label directive 95/12/E
NB: An ASKO dryer can only be stacked safely on an ASKO washer, using the ASKO stacking kit.
NB: The ASKO stacking kit comes with the dryer at no charge when you purchase an ASKO washing machine and an ASKO dryer.
NB: Remaining time indication on T741 and T781 takes approx 10-20 minutes to assess the moisture in the air.
Specifications and product line may vary from country to country. The manufacturer
reserves the right to change specifications without giving prior notice..
Technical specifications
WASHING MACHINES
W6362 W6342 W6222
MODEL
Free-standing machine/Can be built in •/• •/• •/•
Drop down door •--
Colour wh/tit wh/tit wh
DIMENSIONS
Height mm 850 850 850
Width mm 595 595 595
Depth with door open mm 1080 1080 1080
Height adjustment mm 30 30 30
Weight kg 78 73 73
USER INTERFACE
Knob EasyDial EasyDial EasyDial
Microprocessor controlled/Timer micro micro micro
Display •••
WASH PROGRAMS
Auto wash •--
Heavy wash •••
White/Colour wash •••
Quick wash •••
Wool wash •••
Hand wash •••
Additional programs •••
ADDITIONAL PROGRAMS
Temperature selection 30–95°C or cold
3)
•••
Spin Speed rpm
400-1600 400-1400 800/1200
Super-rinse 777
Delayed start h 1-24 1-24 -
OPERATING DATA
1)
Capacity (maximum) kg666
Energy rating stars 4 4 4
Water rating stars 4 4 4
Water remaining after spin. As a percentage of dry weight of wash 44 53 55
Water Consumption l/cycle 58 57 57
Time on Normal Wash mins/cycle 110 110 110
TECHNICAL DATA
Stainless steel inner/outer drum •/• •/• •/•
Balance control •••
Rated voltage V 230 230 240
Frequency Hz 50 50 50
Electrical cord, length mm 2100 2100 2100
Inlet hose length mm 1500 1500 1500
Drain hose length mm 1700 1700 1700
Water outlet via hose/max pumping level mm 900 900 900
WARRANTY
2 year comprehensive parts & labour warranty on all models • • • •
• Standard
1) Based on standard test for 40°C cotton cycle 6 kgs.
2) 200 cycles
3) In front loaders: 30-90°C
In compliance with EN, IEC, EMC standards. CE Marked
NB: Washing machines: Norm EN 60456. Electric washing machine label directive 95/12/EC.
Specifications and product line may vary from country to country. The manufacturer
reserves the right to change specifications without giving prior notice..
