4
The pedestal drawer may only be used with a washing machine and a dryer by the manufacturer Asko Appliances.
1
Press on the pedestal drawer to open it.
2
Use both hands to pull out the pedestal drawer towards
you. Then, push the plastic levers located on the drawer
guides under the drawer on each side towards the middle in
order to release the stop preventing the drawer from being
pulled out completely.
Pull out the entire pedestal drawer.
3
Pull out the shelf in an upward arc.
4
Tilt the washing machine or dryer to either side, and use
a wrench (22 mm) to remove the metal feet.
5.1
Attaching the spacers to the washing machine.
First, screw the supplied nuts onto the spacer. Then, use
an open spanner (22 mm) to attach the spacers to the spot
where the metal feet were previously attached.
5.2
Attaching the spacers to the dryer.
Use an open spanner (22 mm) to attach the spacers to
where the metal feet were previously attached.
Attach the rubber caps onto the spacers in order to protect
your fl oor during installation.
Tilt the machine to the other side and repeat steps 4 and 5.
The pedestal drawer is intended solely for installation under an appliance. The drawer can only support the weight of
one appliance. If a pedestal drawer is installed under a washing machine, do not install a dryer onto the washing machine,
or vice versa.
INSTALLATION AND USE OF A PEDESTAL DRAWER
