EN 26
Removing the oven window
The glass in the oven door can be cleaned from the inside, but you do need to remove the glass
from the door to do this. First remove the oven door (see chapter ‘Removing the oven door’).
• Lift the brackets on the left and right side of the door upwards slightly (to marker 1 on the
bracket) and pull this away from the glass slightly (to marker 2 on the bracket).
• Grasp the glass at the bottom and gently lift this upwards to remove it from the support.
• The inner third glass (depending on the model) can be removed by lifting this carefully and
removing it. Also remove the rubber seals around the glass.
To replace the glass pane, observe the reverse order. The markings (semicircle) on the door and
the glass pane should overlap.
MAINTENANCE
