47
SERVICE
3
Changing the capacitor
1. Remove the rear panel in accordance with the
section "Rear panel - removing...".
2. T720/780: Remove the external fan housing
in accordance with the section "External fan
housing - removing..." steps 2-4.
3. Unscrew the capacitor.
4. Install a new capacitor and connect the wi-
ring.
IMPORTANT
Ensure the wiring connections are correct.
5. T720/780: Install the external fan housing in
accordance with the section "External fan hou-
sing - installation..." steps 5-7.
6. Install the rear panel in accordance with the
section "Rear panel - installation...".
