SERVICE
3
4
2
THERMOSTAT (T700/T720)
Removing the thermostat
1. Remove the three screws at the rear edge and
lift off the top cover.
2. Take off the bottom cover (snap fasteners).
3. Unscrew the protection.
4. Unscrew the thermostats and remove the wi-
ring.
Installing the thermostat
5. Install the thermostats and the wiring.
6. Install the protection, bottom and top covers.
IMPORTANT
Don't forget the 2 star washers for the outermost
screws.
