Reversing the door
You can choose whether the door is hung on the
right or the left.
Follow these instructions:
1. Remove the Toe kick.
2. Remove the hinge (two screws).
3. Lift the door up and remove it. Support the
door while doing this.
4. Remove both door pins (top and bottom).
Fit them on the other side of the machine.
Replace the hinge.
pin
5. Also change the hole plug (A) (on top) and
the door hinge bushing (B) (at the top and on
the bottom), and replace them on the other
side of the door.
(A) (B)
Use a fl at screwdriver to remove the plugs.
NOTE!
Be careful not to damage the appliance with the
screwdriver.
6. Loosen and remove the catch (lift up and
pull out) and the cover plate on the door and
the machine. Switch the catch and the cover
plate.
1
2
7. Refi t the door by loosening the hinge screws
slightly, affi xing the door, and closing it.
Tighten the hinges. Replace the Toe kick.
