ASROCK Rack 1U4LW Series - Add-On Card

20 21
English
3.5 Add-on Card
1. You can install an add-on card to the chassis only when you have a riser card installed on the
server board.
2. Before installing the add-on card, power o the server and unplug the power cord.
Removing the Riser-Card Bracket from the Chassis
1. Hand-release the thumbscrew that secures the riser-card bracket on the chassis.
2. Li up the riser-card bracket.
3. Remove the screw securing the blanking plate on the bracket.
4. Slide the blanking plate out sideways.
4
3
1
2
1
2
