1.2 Specications
ALTRAD8UD-1L / ALTRAD8UD-1L2T
Physical Status
Form Factor Deep Micro-ATX
Dimension 9.6” x 10.5” (24.4cm x 26.7cm)
Processor System
CPU Supports Ampere® Altra®Max/Ampere® Altra® Processor
Socket 1 Socket (LGA-4926)
Chipset System on Chip
System Memory
Supported DIMM
Quantity
8 DIMM slots (1DPC)
Supported Type 288-pin DDR4 RDIMM/LRDIMM
Max. Capacity per
DIMM
256GB
Max. Frequency 3200 MHz
Voltage 1.2V
Note Memory capacity, frequency, and voltage support is to be validated
PCIe Expansion Slots (SLOT7 close to CPU)
SLOT7: PCIe4.0 x16*
SLOT6: PCIe4.0 x16*
SLOT5: PCIe4.0 x16
SLOT4: PCIe4.0 x16**
*Supports PCIe4.0 x8 when using Ampere Altra processors
**SLOT4 does not support full-length card
Other PCIe Expansion Connectors
M.2 2 M-key (PCIe4.0 x4); support 2230/2280 form factor
SlimSAS 4 SlimSAS (PCIe4.0 x8)
OCuLink 2 OCuLink (PCIe4.0 x4)
Ethernet
Additional
Ethernet
Controller
ALTRAD8UD-1L:
Intel® i210: 1 RJ45 (1GbE)
ALTRAD8UD-1L2T:
Intel® X550: 2 RJ45 (10GbE)
Intel® i210: 1 RJ45 (1GbE)
Graphics
Controller ASPEED AST2500
VRAM DDR4 512MB
Rear I/O
UID Button/LED 1 UID button w/ LED
