ASROCK Rack X570D4I-2T User Manual

X570D4I-2T
2 3
English
LAN Port - RJ45: 2x 10GLAN(by Intel® X550-AT2)
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
Management
LAN Port
1
UID 1
Internal Connector
ITX_AUX_
PANEL1
1
PANEL1 1
TR1 1
TPM Header 1
Fan Header 3x (4-pin)
ATX power DC-
IN
1x (8-pin)
ATX 4-PIN
Power
1x (4-pin)
SATA Power 1x (4-pin)
OCuLink 2
USB 3.1 Gen1
Header
1 (supports 2 USB3.1 Gen1)
ClearCMOS 1 (short pad)
COM Header 1
IPMB 1
PWR SMB 1
BMC_SMB 1
OH/FanFail
LED
3
System BIOS
BIOS Ty pe 256Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8.0 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU/PCH/DDR/LAN/Storage Temperature Sensing
- MB/Card side/TR1 Temperature Sensing
Fan - CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by
CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: 3VSB, 5VSB, VCPU, VSOC, VCCM, APU
VDDP, PM VDD CLDO, PM VDDCR S5, PM VDDCR, BAT,
3V, 5 V, 12V
