4 5
English
VRAM DDR4 16MB
Rear Panel I/O
VGA Port 1 x D-Sub
Serial Port 1 x COM port
USB 3.2 (Gen2)
Port
2
HDMI 1 (only supported for Picasso(APU))
LAN Port X570D4U-2L2T:
- 2 x RJ45 1 Gigabit Ethernet LAN ports
- 2 x RJ45 10 Gigabit Ethernet LAN ports
- 1 x RJ45 Dedicated IPMI LAN port
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
X570D4U:
- 2 x RJ45 1 Gigabit Ethernet LAN ports
- 1 x RJ45 Dedicated IPMI LAN port
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
UID 1
Internal Connector
Auxiliary Panel
Header
1 (includes chassis intrusion, location button & LED, front
LAN LED, system fault, and BMC alert)
Front Panel 1 (RST, PWRBTN, HDDLED, PWRLED)
TPM Header 1 (17-pin LPC TPM header, supports TPM 1.2/2.0)
SPI TPM Header 1 (13-pin SPI TPM header, supports TPM 2.0)
IPMB Header 1
Fan Header 3 (6-pin), 3 (4-pin)
ATX Power 1 x (24-pin) + 1 x (4-pin)
USB 3.2 Gen1
Header
1 (supports 2 USB 3.2 Gen1 ports)
M.2 2
SATA DOM 1
BMC_SMB1 1
PSU_SMB1 1
SPEAKER 1
TR1 1
Front VGA 1
Front LAN LED X570D4U-2L2T: 1
X570D4U: N/A
80 debug port LED 1
Buzzer 1
Clear CMOS 1 (short pad)
