ASROCK Rack X570D4U-2L2T User Manual

X570D4U-2L2T / X570D4U
2 3
English
PCIe 3.0/4.0 x 1 Matisse:
PCIE5: Gen4 x1 link
Picasso:
PCIE5: Gen3 x1 link
Renoir:
PCIE5: Gen3 x1 link
Storage
SATA Controller 8 x SATA3 6.0 Gb/s (SATA0-7, SATA_0 supports SATA DOM),
support RAID 0, 1, 10
M.2 Slot 2 (M2_1: 2242/2260/2280/22110, supports SATA3 (6.0 Gb/s) or
PCIE4.0(x4)(Matisse) / PCIE3.0(Renoir/Picasso)(x4) ;
M2_2: 2242/2260/2280, supports SATA3 (6.0 Gb/s) or
PCIE4.0(x4)(Matisse) / PCIE3.0(Renoir/Picasso)(x4)
Ethernet
Interface X570D4U-2L2T:
10000/1000 /100 /10 Mbps
X570D4U:
1000 /100 /10 Mbps
LAN Controller X570D4U-2L2T:
- 2 x RJ45 10G base-T by Intel® X550-AT2
- 2x RJ45 1G base-T by Intel® I210-AT
- 1 x RJ45 Dedicated IPMI LAN port by RTL8211E
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN3 supports NCSI
X570D4U:
- 2x RJ45 1G base-T by Intel® I210-AT
- 1 x RJ45 Dedicated IPMI LAN port by RTL8211E
- Supports Wake-On-LAN
- Supports Energy Ecient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
Management
BMC Controller ASPEED AST2500
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management GLAN
Features Watch Dog
Graphics
Controller ASPEED AST2500
