Thank you for purchasing ASRock 4Core1600P35-WiFi+ / 4Core1600P35-WiFi
motherboard, a reliable motherboard produced under ASRock’s consistently stringent
quality control. It delivers excellent performance with robust design conforming to ASRock’s
commitment to quality and endurance.
In this manual, chapter 1 and 2 contain introduction of the motherboard and step-by-step
guide to the hardware installation. Chapter 3 and 4 contain the configuration guide to
BIOS setup and information of the Support CD.
Because the motherboard specifications and the BIOS software might
be updated, the content of this manual will be subject to change without
notice. In case any modifications of this manual occur, the updated
version will be available on ASRock website without further notice. You
may find the latest VGA cards and CPU support lists on ASRock website
as well. ASRock website
http://www.asrock.com
If you require technical support related to this motherboard, please visit
our website for specific information about the model you are using.
www.asrock.com/support/index.asp
1.1 P1.1 P
1.1 P1.1 P
1.1 P
ackack
ackack
ack
age Contentsage Contents
age Contentsage Contents
age Contents
ASRock 4Core1600P35-WiFi+ / 4Core1600P35-WiFi Motherboard
(ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm)
ASRock 4Core1600P35-WiFi+ / 4Core1600P35-WiFi Quick Installation Guide
ASRock 4Core1600P35-WiFi+ / 4Core1600P35-WiFi Support CD
ASRock WiFi-802.11g Module Operation Guide
Motherboard Accessories
One 80-conductor Ultra ATA 66/100/133 IDE Ribbon Cable
One Ribbon Cable for a 3.5-in Floppy Drive
Four Serial ATA (SATA) Data Cables (Optional)
One Serial ATA (SATA) HDD Power Cable (Optional)
One HDMI_SPDIF Cable (Optional)
One “ASRock 1394_eSATAII I/O Plus” I/O Panel Shield (4Core1600P35-WiFi+)
One “ASRock 8CH_eSATAII I/O Plus” I/O Panel Shield (4Core1600P35-WiFi)
WiFi Accessories
One ASRock WiFi-802.11g Module
One Antenna
One WiFi Bracket
