ASROCK 770 Extreme3 User Manual

5353
5353
53
BIOS SETUP UTILITY
Main OC Tweaker Advanced H/W Monitor
Security Exit
Boot Settings
Configure Settings
during System Boot.
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
Boot
Boot Settings Configuration
1st Boot Device
2nd Boot Device
3rd Boot Device
4th Boot Device
Hard Disk Drives
Removable Drives
CD/DVD Drives
[1st Floppy Device]
[HDD: PM - HDS722580VL]
[CD/DVD: 3S-CD-ROM C]
[USB]
BIOS SETUP UTILITY
Boot Settings Configuration
Disabled: Displays
normal POST messages.
Enabled: Displays OEM
Logo instead of POST
messages.
Select Screen
Select Item
+ - Change Option
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2003, American Megatrends, Inc.
Boot
AddOn ROM Display
Boot Logo
Boot From Onboard LAN
Bootup Num-Lock
[Enabled]
[Auto]
[Disabled]
[On]
Full Screen Logo
[Enabled]
3.63.6
3.63.6
3.6
Boot ScreenBoot Screen
Boot ScreenBoot Screen
Boot Screen
In this section, it will display the available devices on your system for you to config-
ure the boot settings and the boot priority.
3.6.13.6.1
3.6.13.6.1
3.6.1
Boot Settings ConfigurationBoot Settings Configuration
Boot Settings ConfigurationBoot Settings Configuration
Boot Settings Configuration
Full Screen Logo
Use this item to enable or disable OEM Logo. The default value is [Enabled].
AddOn ROM Display
Use this option to adjust AddOn ROM Display. If you enable the option
“Full Screen Logo” but you want to see the AddOn ROM information when
the system boots, please select [Enabled]. Configuration options: [Enabled]
and [Disabled]. The default value is [Enabled].

ASROCK 770 Extreme3 Specifications

General

Non-ECC	Yes
Number of memory slots	4
Maximum internal memory	16 GB
Processor socket	Socket AM3
Processor manufacturer	AMD
USB 2.0 connectors	3
Number of COM connectors	1
Number of SATA connectors	6
I/O ports	2 x SATA3 4 x SATAII 1 x IR
Special features	- ASRock OC Tuner - Intelligent Energy Saver - Instant Boot - ASRock Instant Flash - ASRock OC DNA - Hybrid Booster: - CPU Frequency Stepless Control - ASRock U-COP - Boot Failure Guard (B.F.G.)
Controller interface type	SATAII
PS/2 ports quantity	2
USB 2.0 ports quantity	5
Firewire (IEEE 1394) ports	0
Audio chip	Realtek ALC892
Certification	FCC, CE, WHQL, EuP Ready
Motherboard chipset	AMD 770
Audio output channels	7.1 channels
Motherboard form factor	ATX
Compatible operating systems	Windows 7/7 64-bit/Vista/Vista 64-bit/XP/XP Media Center/XP 64-bit
RAID levels	0, 1
LAN controller	Realtek RTL8111D(L)
Networking features	10/100/1000 Mb/s
BIOS type	AMI
ACPI version	1.1
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	208 mm
Width	305 mm
