ASROCK 970 Pro - Motherboard Layout

1010
1010
10
1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout1.3 Motherboard Layout
1.3 Motherboard Layout
FSB800
DDR3_A1 (64 bit, 240-pin module)
DDR3_B1 (64 bit, 240-pin module)
FSB800
DDR3_A2 (64 bit, 240-pin module)
DDR3_B2 (64 bit, 240-pin module)
AMD
SB710
Chipset
PS2_USB_PW1
1
ATX12V1
CPU_FAN1
8Mb
BIOS
CMOS
BATTERY
CLRCMOS1
1
LAN
PHY
AUDIO
CODEC
Super
I/O
IR1
1
HD_AUDIO1
1
PCIE1
HDLED RESET
PLED PWRBTN
1
PANEL 1
CHA_FAN1
SPEAKER1
1
USB8_9
1
USB6_7
1
SATAII_4
AM3
HT 3.0
Phenom II
140W CPU
20.8cm (8.2-in)
30.5cm (12.0-in)
6
7
1
2
4
3
5
8
9
10
11
12
13
14
15
16
17
1819
20212223
24
25
26
27
28
29
30
31
32
AMD
770
Chipset
PCIE2
PCI1
PCI2
SATAII_6
SATAII_3
SATAII_5
Top:
LINE IN
Center:
FRONT
Bottom:
MIC IN
PS2
Mouse
PS2
Keyboard
USB 2.0
T: USB0
B: USB1
Top:
RJ-45
USB 2.0
T: U SB 2
B: USB3
FSB2.6GHz DDR3 1600 Dual Channel
PCI Express 2.0
ErP/EuP Ready
RoHS
USB10_11
1
PWR_FAN1
33
34
COM1
USB 2.0
T: U SB 4
B: USB5
PCIE3
SATAII_2
SATAII_1
PLED1
1
PS2_USB_PW2
1
PS2_USB_PW3
1
PS2_USB_PW4
1
35
970 Pro
Designed in Taipei
Support 6-Core CPU
SOCKET AM3b
1 PS2_USB_PW1 Jumper 18 Chassis Speaker Header (SPEAKER1)
2 ATX 12V Power Connector (ATX12V1) 19 Clear CMOS Jumper (CLRCMOS1)
3 AM3+ CPU Socket 20 Power LED Header (PLED1)
4 CPU Heatsink Retention Module 21 System Panel Header (PANEL1)
5 CPU Fan Connector (CPU_FAN1) 22 USB 2.0 Header (USB6_7)
6 2 x 240-pin DDR3 DIMM Slots 23 PS2_USB_PW2 Jumper
(Dual Channel A: DDR3_A1, DDR3_B1) 24 USB 2.0 Header (USB8_9)
7 2 x 240-pin DDR3 DIMM Slots 25 PS2_USB_PW3 Jumper
(Dual Channel B: DDR3_A2, DDR3_B2) 26 USB 2.0 Header (USB10_11)
8 ATX Power Connector (ATXPWR1) 27 PS2_USB_PW4 Jumper
9 SPI Flash Memory (8Mb) 28 Front Panel Audio Header
10 Southbridge Controller (HD_AUDIO1)
11 SATA2 Connector (SATAII_5) 29 Infrared Module Header (IR1)
12 SATA2 Connector (SATAII_6) 30 PCI Slots (PCI1-2)
13 SATA2 Connector (SATAII_4) 31 PCI Express x1 Slot (PCIE3)
14 SATA2 Connector (SATAII_3) 32 PCI Express x16 Slot (PCIE2)
15 Chassis Fan Connector (CHA_FAN1) 33 PCI Express x1 Slot (PCIE1)
16 SATA2 Connector (SATAII_1) 34 Power Fan Connector (PWR_FAN1)
17 SATA2 Connector (SATAII_2) 35 Northbridge Controller
