ASROCK 970M Pro3 Manual

24
Deutsch
Audio
•
7.1-Kanal-HD-Audio mit Inhaltsschutz (Realtek ALC892-
Audiocodec)
*Zur Konguration von 7.1-Kanal-HD-Audio müssen Sie ein
HD-Frontblenden-Audiomodul nutzen und den Mehrkanalton
•
über den Audiotreiber aktivieren.
•
Erstklassige Blu-ray-Audiounterstützung
•
Unterstützt Überspannungsschutz (ASRock Full Spike
Protection)
•
ELNA Audio Caps.
LAN
•
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
•
Realtek RTL8111E
•
Unterstützt Wake-On-LAN
•
Unterstützt Blitzschutz/Schutz gegen elektrostatische Entla-
dung (ASRock Full Spike Protection)
•
Unterstützt LAN-Kabelerkennung
•
Unterstützt energieezientes Ethernet 802.3az
•
Unterstützt PXE
Rückblen-
de, E/A
•
1 x PS/2-Mausanschluss
•
1 x PS/2-Tastaturanschluss
•
6 x USB 2.0-Ports (unterstützt Schutz gegen elektrostatische
Entladung (ASRock Full Spike Protection))
•
2 x USB 3.0-Ports (Etron EJ188H) (unterstützt Schutz gegen
elektrostatische Entladung (ASRock Full Spike Protection))
•
1 x RJ-45-LAN-Port mit LED (Aktivität/Verbindung-LED
und Geschwindigkeit-LED)
•
HD-Audioanschluss: Line-in / Vorderer Lautsprecher /
Mikrofon
Speicher
•
6 x SATA-III-6,0-Gb/s-Anschlüsse, unterstützt RAID (RAID
0, RAID 1, RAID 5 und RAID 10), NCQ, AHCI und „Hot-
Plugging“
Anschluss
•
1 x IR-Stileiste
•
1 x Betrieb-LED-Stileiste
•
1 x CPU-Lüeranschlüsse (4-polig)
•
1 x Gehäuselüeranschlüsse (4-polig)
•
1 x Netzteillüeranschluss (3-polig)

ASROCK 970M Pro3 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2100, 2400 MHz
Processor socket	Socket AM3+
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6
Processor thermal power (max)	140 W
USB 2.0 connectors	2
Number of SATA connectors	-
Number of SATA III connectors	6
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC892
Component for	PC
Power source type	ATX
Motherboard chipset	AMD 970
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Motherboard southbridge	AMD SB950
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Parallel processing technology support	2-Way CrossFireX, Quad-GPU CrossFireX
BIOS type	UEFI AMI
ACPI version	1.1
BIOS memory size	32 Mbit
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	- mm
