2
English
No. Description
1 ATX 12V Power Connector (ATX12V2)
2 CPU Fan Connector (CPU_FAN1)
3 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
4 2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2)
5 ATX Power Connector (ATXPWR1)
6 Power Fan Connector (PWR_FAN1)
7 SATA3 Connector (SATA3_5)
8 SATA3 Connector (SATA3_6)
9 SATA3 Connector (SATA3_4)
10 SATA3 Connector (SATA3_3)
11 SATA3 Connector (SATA3_1)
12 SATA3 Connector (SATA3_2)
13 System Panel Header (PANEL1)
14 Chassis Speaker Header (SPEAKER1)
15 Power LED Header (PLED1)
16 USB 2.0 Header (USB_8_9)
17 USB 2.0 Header (USB_10_11)
18 Clear CMOS Jumper (CLRCMOS1)
19 Infrared Module Header (IR1)
20 TPM Header (TPMS1)
21 Front Panel Audio Header (HD_AUDIO1)
22 USB 3.0 Header (USB3_2_3)
23 Chassis Fan Connector (CHA_FAN1)
