ASROCK 980DE3/U3S3 Quick Installation Guide

128
ASRock 980DE3/U3S3 Motherboard
1.2 主板規格
架构 - ATX 規格
- 全固態電容設計
處理器 - 支持 Socket AM3+ 處理器
- 支持 Socket AM3 處理器 : AMD Phenom
TM
II X6 / X4 /
X3 / X2(920/940 除外 ) / Athlon II X4 / X3 / X2 /
Sempron 處理器
- 八核心 CPU 就緒
- Digi 電源設計
- 支持高達 140W 的 CPU
- 通過 ACC ( 高級時鐘校准 ) 功能支持 AMD OverDrive
TM
系統調
節
- 支持 AMD Cool
‘
n
’
Quiet
™
冷靜技術
- 支持 FSB 2600 MHz (5.2 GT/s)
- 支持異步超頻技術
- 支持 Hyper-Transport 3.0 (HT 3.0) 技術
芯片組 - 北橋 : AMD RX881/760G
- 南橋 : AMD SB710
系統內存 - 支持雙通道內存技術
- 配備 4 個 DDR3 DIMM 插槽
- 支持 DDR3 1866( 超頻 )/1600( 超頻 )/1333/1066/800
non-ECC、un-buffered 內存
- 系統最高支持 32GB 容量
擴展插槽 - 1 x PCI Express 2.0 x16 插槽 (PCIE3: x16 模式 )
- 3 x PCI Express 2.0 x1 插槽
- 2 x PCI 插槽
音效 - 5.1 聲道高保真音頻 (Realtek ALC662 音頻編解碼器 )
- 支持 THX TruStudio
TM
板載 LAN 功能 - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111E
- 支持网路喚醒（Wake-On-LAN）
- 支持網路線偵測功能
- 支持 Energy Efficient Ethernet 802.3az
- 支持 PXE
Rear Panel I/O 界面
I/O - 1 個 PS/2 鼠標接口
( 后面板輸入 / - 1 個 PS/2 鍵盤接口
輸出接口 ) - 1 個串行接口 : COM1
- 4 個可直接使用的 USB 2.0 接口
- 2 個可直接使用的 USB 3.0 接口
簡體中文

ASROCK 980DE3/U3S3 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	800, 1066, 1333, 1600, 1866 MHz
System bus rate	5.2 GT/s
Processor socket	Socket AM3+
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6
Processor thermal power (max)	140 W
Maximum number of SMP processors	1
Processor system buses supported	2600 MHz
USB 2.0 connectors	3
Number of SATA II connectors	6
Number of SATA III connectors	2
eSATA ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cooling type	Passive
Certification	FCC, CE, WHQL, ErP/EuP
Component for	PC
Motherboard chipset	AMD 760G
Audio output channels	5.1 channels
Motherboard form factor	ATX
Motherboard southbridge	AMD SB710
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	IDE, SATA II, SATA III
Parallel processing technology support	-
Cables included	SATA
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	1.1
BIOS memory size	16 Mbit

Weight and Dimensions

Width	- mm
