ASROCK 980DE3/U3S3 Quick Installation Guide

140
ASRock 980DE3/U3S3 Motherboard
繁體中文
- 1 個 RJ-45 區域網接口與 LED 指示燈 (ACT/LINK LED 和
SPEED LED)
- 高清晰音效插孔：音效輸入 / 前置喇叭 / 麥克風
SATA3 - 2 x ASMedia ASM1061 的 SATA3 6.0Gb/s 接頭，支援 NCQ,
AHCI 和熱插拔功能
USB 3.0 - 2 x Etron EJ188的後置USB 3.0接頭，支援USB 1.1/2.0/3.0
到 5Gb/s
- 1 x Etron EJ188 的前置 USB 3.0 接頭 ( 支援 2 個 USB 3.0
接頭 )，支援 USB 1.1/2.0/3.0 到 5Gb/s
接頭 - 6 x SATA2 3.0Gb/s 接頭 , 支援 RAID (RAID 0, RAID 1,
RAID 10 和 JBOD), NCQ, AHCI 和熱插拔功能
- 2 x SATA3 6.0Gb/s 接頭
- 1 x ATA133 IDE 插座 ( 最高支援 2 個 IDE 驅動器 )
- 1 x 磁碟機接頭
- 1 x 紅外線模組接頭
- 1 x HDMI_SPDIF 接頭
- 1 x 電源指示燈接頭
- 1 x CPU 風扇接頭 (4 針 )
- 1 x 機箱風扇接頭 (4 針 )
- 1 x 電源風扇接頭 (4 針 )
- 24 針 ATX 電源接頭
- 8 針 12V 電源接頭
- 內置音效接頭
- 前置音效接頭
- 3 x USB 2.0 接口 ( 可支援 6 個額外的 USB 2.0 接口 )
- 1 x USB 3.0 接頭 ( 可支援 2 個額外的 USB 3.0 接口 )
BIOS - 16Mb AMI Legal BIOS
- 支援即插即用（Plug and Play,PnP）
- ACPI 1.1 電源管理
- 支援喚醒功能
- 支援 jumperfree 免跳線模式
- 支援 SMBIOS 2.3.1
- CPU,VCCM,NB 電壓多功能調節器
支援光碟 - 驅動程式、工具軟體、防毒軟體（試用版本 )、AMD
OverDrive
TM
、CyberLink MediaEspresso 6.5 試用版、華擎
MAGIX 多媒體套餐 - OEM、Google Chrome Browser 和
Toolbar
硬體監控器 - CPU 溫度偵測
- 主板溫度偵測
- CPU/ 機箱 / 電源風扇轉速計
- CPU 靜音風扇
- CPU/ 機箱 / 電源風扇多速控制

ASROCK 980DE3/U3S3 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	800, 1066, 1333, 1600, 1866 MHz
System bus rate	5.2 GT/s
Processor socket	Socket AM3+
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6
Processor thermal power (max)	140 W
Maximum number of SMP processors	1
Processor system buses supported	2600 MHz
USB 2.0 connectors	3
Number of SATA II connectors	6
Number of SATA III connectors	2
eSATA ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cooling type	Passive
Certification	FCC, CE, WHQL, ErP/EuP
Component for	PC
Motherboard chipset	AMD 760G
Audio output channels	5.1 channels
Motherboard form factor	ATX
Motherboard southbridge	AMD SB710
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	IDE, SATA II, SATA III
Parallel processing technology support	-
Cables included	SATA
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	1.1
BIOS memory size	16 Mbit

Weight and Dimensions

Width	- mm
