ASROCK 980DE3/U3S3 Quick Installation Guide

150
ASRock 980DE3/U3S3 Motherboard
- HD Audio Jack: Line in / Penyuara Depan / mikropon
SATA3 - 2 x penghubung SATA3 6.0Gb/s dari ASMedia ASM1061,
dapat digunakan NCQ, AHCI dan fungsi fungsi “Hot Plug”
USB 3.0 - 2 x Port Belakang USB 3.0 dari Etron EJ188, mendukung
USB 1.1/2.0/3.0 hingga 5Gb/s
- 1 x Port Depan USB 3.0 dari Etron EJ188 (menggunakan
2 port USB 3.0), mendukung USB 1.1/2.0/3.0 hingga 5Gb/s
Penghubung - 6 x penghubung SATA2 3.0Gb/s, dapat digunakan RAID
(RAID 0, RAID 1, RAID 10 dan JBOD), NCQ, AHCI, dan
fungsi fungsi “Hot Plug”
- 2 x penghubung SATA3 6.0Gb/s
- 1 x Penghubung ATA133 IDE
(menggunakan perlengkapan 2 x IDE)
- 1 x Penghubung Floppy
- 1 x header IR
- 1 x HDMI_SPDIF header
- 1 x header power LED
- 1 x Penghubung KIPAS CPU (4 pin)
- 1 x Penghubung KIPAS casis (4 pin)
- 1 x Penghubung KIPAS Power (4 pin)
- Penghubung power 24 pin ATX
- Penghubung power 8 pin 12V
- CD dalam header
- Penghubung audio panel dapan
- 3 x USB 2.0 header (menggunakan 6 port USB 2.0)
- 1 x USB 3.0 header (menggunakan 2 port USB 3.0)
Ciri-ciri BIOS - 16Mb AMI Legal BIOS
- Menggunakan “Plug and Play”
- ACPI 1.1 Compliance Wake Up Events
- Menggunakan jumperfree
- Penyokong AMBIOS 2.3.1
- Penyesuaian berbagai tegangan CPU, VCCM, NB
Sokongan CD - Penggerak, kegunaan, Software AntiVirus (Versi Cobaan),
AMD OverDrive
TM
, CyberLink MediaEspresso 6.5 Trial,
ASRock MAGIX Multimedia Suite - OEM, Google Chrome
Browser dan Toolbar
Penjaga - Perasa Suhu CPU
Hardware - Perasa Suhu Casis
- Pengukur Kipas CPU/Casis/Power
- Kipas diam CPU
- Kontrol Multi-Kecepatan Kipas CPU/Casis/Power
Bahasa Indonesia

ASROCK 980DE3/U3S3 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	800, 1066, 1333, 1600, 1866 MHz
System bus rate	5.2 GT/s
Processor socket	Socket AM3+
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6
Processor thermal power (max)	140 W
Maximum number of SMP processors	1
Processor system buses supported	2600 MHz
USB 2.0 connectors	3
Number of SATA II connectors	6
Number of SATA III connectors	2
eSATA ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cooling type	Passive
Certification	FCC, CE, WHQL, ErP/EuP
Component for	PC
Motherboard chipset	AMD 760G
Audio output channels	5.1 channels
Motherboard form factor	ATX
Motherboard southbridge	AMD SB710
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	IDE, SATA II, SATA III
Parallel processing technology support	-
Cables included	SATA
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	1.1
BIOS memory size	16 Mbit

Weight and Dimensions

Width	- mm
