ASROCK 980DE3/U3S3 Quick Installation Guide

85
ASRock 980DE3/U3S3 Motherboard
Português
1.2 Especifi cações
Plataforma - Formato ATX
- Design de condensadores banhados a ouro de alta qualidade
CPU
- Suporte para processadores AM3+
- Suporte para processadores AM3: Processador AMD
Phenom
TM
II X6 / X4 / X3 / X2 (exceto 920 / 940) / Athlon II X4
/ X3 / X2 / Sempron
- Preparado para CPU de oito núcleos
- Design de Poder Digital
- Suporta CPU até 140W
- Suporta a tecnologia AMD OverDrive
TM
com ACC (Advanced
Clock Calibration)
- Suporta a tecnologia Cool ‘n’ Quiet da AMD
- FSB de 2600 MHz (5,2 GT/s)
- Suporta a tecnologia Untied Overclocking
- Suporta a tecnologia Hyper-Transport 3.0 (HT 3.0)
Chipsets - North Bridge: AMD RX881/760G
- South Bridge: AMD SB710
Memória
- Suporte à tecnologia de memória de duplo canal
- 4 x slots de DDR3 DIMM
- Suporta memória DDR3 1866(OC)/1600(OC)/1333/1066/800,
não ECC, sem tampão
- Capacidade máxima de memória do sistema: 32GB
Slots de - 1 x slot de PCI Express 2.0 x16 (PCIE3: modo x16)
Expansão
- 3 x slots de PCI Express 2.0 x1
- 2 x slots de PCI
Áudio - Áudio HD de 5.1 canais (Realtek ALC662 Audio Codec)
- Suporta TruStudio
TM
da THX
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111E
- Suporta Wake-On-LAN
- Suporta Detecção de cabo LAN
- Suporta Ethernet com Efi ciência Energética 802.3az
- Suporta PXE
Entrada/Saída I/O Panel
pelo painel - 1 x porta para mouse PS/2
- 1 x porta para teclado PS/2
- 1 x porta COM1
- 4 x portas USB 2.0 padrão
- 2 x portas USB 3.0 padrão

ASROCK 980DE3/U3S3 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	800, 1066, 1333, 1600, 1866 MHz
System bus rate	5.2 GT/s
Processor socket	Socket AM3+
Processor manufacturer	AMD
Compatible processor series	AMD Phenom II X2, AMD Phenom II X3, AMD Phenom II X4, AMD Phenom II X6
Processor thermal power (max)	140 W
Maximum number of SMP processors	1
Processor system buses supported	2600 MHz
USB 2.0 connectors	3
Number of SATA II connectors	6
Number of SATA III connectors	2
eSATA ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cooling type	Passive
Certification	FCC, CE, WHQL, ErP/EuP
Component for	PC
Motherboard chipset	AMD 760G
Audio output channels	5.1 channels
Motherboard form factor	ATX
Motherboard southbridge	AMD SB710
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
RAID levels	0, 1, 10, JBOD
Supported storage drive interfaces	IDE, SATA II, SATA III
Parallel processing technology support	-
Cables included	SATA
LAN controller	Realtek RTL8111E
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	1.1
BIOS memory size	16 Mbit

Weight and Dimensions

Width	- mm
