ASROCK A320M-HDV R3.0 User Manual

A320M-HD
3
English
•
1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode) (If you use
Athlon 200GE APU, PCIE2 slot will run at x4 mode.)*
* Supports NVMe SSD as boot disks
•
1 x PCI Express 2.0 x1 Slot
Graphics
•
Integrated AMD Radeon
TM
R7 Series Graphics in A-series /
E-series APU
•
DirectX 12, Pixel Shader 5.0
•
Shared memory default 2GB, Max Shared memory supports
up to 16GB.
* e Max shared memory 16 GB requires 32 GB system memory
installed.
•
Dual graphics output: Support HDMI and D-Dub ports by
independent display controllers
•
Supports HDMI with max. resolution up to 4K x 2K
(4096x2160) @ 24Hz / (3840x2160) @ 30Hz
•
Supports D-Sub with max. resolution up to 2048x1536 @
60Hz
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI Port (Compliant
HDMI monitor is required)
•
Supports HDCP with HDMI Port
•
Supports Full HD 1080p Blu-ray (BD) playback with HDMI
Port
Audio
•
7.1 CH HD Audio (Realtek ALC887 Audio Codec)
* To congure 7.1 CH HD Audio, it is required to use an HD
front panel audio module and enable the multi-channel audio
feature through the audio driver.
•
Supports Surge Protection
•
ELNA Audio Caps
LAN
•
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
•
Realtek RTL8111GR
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports LAN Cable Detection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE

ASROCK A320M-HDV R3.0 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200 MHz
Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD A, AMD Athlon, AMD Athlon X4, AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Number of SATA II connectors	0
Number of SATA III connectors	4
Number of Parallel ATA connectors	-
PS/2 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111GR
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Audio chip	Realtek ALC887
Certification	- FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required)
Component for	PC
Motherboard chipset	AMD A320
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 10
Maximum resolution	4096 x 2160 pixels
Number of displays supported	3
BIOS type	UEFI AMI
ACPI version	5.1
BIOS memory size	16 Mbit
System Management BIOS (SMBIOS) version	2.3
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	201 mm
Width	230 mm
