ASROCK A320M-HDV R3.0 User Manual

English
4
Rear Panel
I/O
•
1 x PS/2 Mouse/Keyboard Port
•
2 x USB 2.0 Ports (Supports ESD Protection)
•
4 x USB 3.1 Gen1 Ports (Supports ESD Protection)
•
1 x D-Sub Port
•
1 x HDMI Port
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jacks: Line in / Front Speaker / Microphone
Storage
•
4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
•
1 x Ultra M.2 Socket, supports M Key type 2242/2260/2280
M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up
to Gen3 x4 (32 Gb/s) (with Summit Ridge, Raven Ridge and
Pinnacle Ridge) or Gen3 x2 (16 Gb/s) (with A-Series APU)*
* Supports NVMe SSD as boot disks
* Supports ASRock U.2 Kit
Connector
•
1 x Print Port Header
•
1 x COM Port Header
•
1 x TPM Header
•
1 x Chassis Intrusion and Speaker Header
•
1 x CPU Fan Connector (4-pin)
•
2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin)
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
1 x 24 pin ATX Power Connector
•
1 x 4 pin 12V Power Connector
•
1 x Front Panel Audio Connector
•
2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD
Protection)
•
1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports)
(Supports ESD Protection)
BIOS
Feature
•
AMI UEFI Legal BIOS with GUI support
•
Supports “Plug and Play”
•
ACPI 5.1 compliance wake up events
•
Supports jumperfree
•
SMBIOS 2.3 support
•
DRAM Voltage multi-adjustment

ASROCK A320M-HDV R3.0 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200 MHz
Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD A, AMD Athlon, AMD Athlon X4, AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Number of SATA II connectors	0
Number of SATA III connectors	4
Number of Parallel ATA connectors	-
PS/2 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111GR
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
Audio chip	Realtek ALC887
Certification	- FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required)
Component for	PC
Motherboard chipset	AMD A320
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
RAID levels	0, 10
Maximum resolution	4096 x 2160 pixels
Number of displays supported	3
BIOS type	UEFI AMI
ACPI version	5.1
BIOS memory size	16 Mbit
System Management BIOS (SMBIOS) version	2.3
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	201 mm
Width	230 mm
