9
CAUTION!
1. This motherboard supports Dual Channel Memory Technology. Before
you implement Dual Channel Memory Technology, make sure to read the
installation guide of memory modules on page 15 for proper installation.
2. Whether 2400/1866/1600MHz memory speed is supported depends on
the CPU you adopt. If you want to adopt DDR3 2400/1866/1600 memory
module on this motherboard, please refer to the memory support list on
our website for the compatible memory modules.
ASRock website http://www.asrock.com
3. Due to the operating system limitation, the actual memory size may be
less than 4GB for the reservation for system usage under Windows
®
7 /
Vista
TM
/ XP. For Windows
®
64-bit OS with 64-bit CPU, there is no such
limitation.
4. The maximum shared memory size is de ned by the chipset vendor and
is subject to change. Please check AMD website for the latest informa-
tion.
5. xvYCC and Deep Color are only supported under Windows
®
7 64-bit /
7. Deep Color mode will be enabled only if the display supports 12bpc
in EDID. HBR is supported under Windows
®
7 64-bit / 7 / Vista
TM
64-bit /
Vista
TM
.
6. ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to ne-tune
different system functions in a user-friendly interface, which is including
Hardware Monitor, Fan Control and IES. In Hardware Monitor, it shows
the major readings of your system. In Fan Control, it shows the fan speed
and temperature for you to adjust. In IES (Intelligent Energy Saver), the
voltage regulator can reduce the number of output phases to improve
efficiency when the CPU cores are idle without sacrificing computing
performance. Please visit our website for the operation procedures of
ASRock Extreme Tuning Utility (AXTU).
ASRock website: http://www.asrock.com
7. ASRock Instant Flash is a BIOS ash utility embedded in Flash ROM.
This convenient BIOS update tool allows you to update system BIOS
without entering operating systems rst like MS-DOS or Windows
®
. With
this utility, you can press <F6> key during the POST or press <F2> key to
BIOS setup menu to access ASRock Instant Flash. Just launch this tool
and save the new BIOS le to your USB ash drive, oppy disk or hard
drive, then you can update your BIOS only in a few clicks without prepar-
ing an additional oppy diskette or other complicated ash utility. Please
be noted that the USB ash drive or hard drive must use FAT32/16/12 le
system.

Table of Contents

Other manuals for ASROCK A55M-HVS

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK A55M-HVS and is the answer not in the manual?

ASROCK A55M-HVS Specifications

General IconGeneral
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR3-SDRAM
Maximum internal memory16 GB
Supported memory clock speeds800, 1066, 1333, 1600, 1866, 2400 MHz
Processor socketSocket FM1
Processor manufacturerAMD
Compatible processor seriesAMD Sempron
Processor thermal power (max)100 W
USB 2.0 connectors3
Number of COM connectors1
Number of SATA II connectors6
USB 3.2 Gen 1 (3.1 Gen 1) connectors0
HDMI version1.4a
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chipVIA VT1705
Cooling typePassive
CertificationFCC, CE, WHQL, ErP/EuP
Component forPC
Power source typeATX
Motherboard chipsetAMD A55 FCH
Audio output channels5.1 channels
Motherboard form factormicro ATX
Compatible operating systemsWindows 7\\r Windows Vista\\r Windows XP
RAID levels0, 1, 10
Supported storage drive interfacesSATA II
On-board graphics cardNo
Parallel processing technology supportNot supported
PCI Express slots version2.0
Cables includedSATA
LAN controllerRealtek RTL8111E
Networking featuresGigabit Ethernet
Ethernet interface typeFast Ethernet, Gigabit Ethernet
BIOS typeAMI
ACPI version1.1
BIOS memory size32 Mbit
Weight and Dimensions IconWeight and Dimensions
Depth216 mm
Width226 mm
