ASROCK A75 Pro4/MVP User Manual

12
1.3 Motherboard Layout
   
   
   
   
   
   
   
    
   
   
   
    
   
   
   
   
   
   
   
    
   
   
  
Super
I/O
CM OS
BA TTE RY
ATXPWR1
AMD
A75 F CH
(Hudson-D3)
Chipset
COM1
PCIE 1
PCI1
LAN
AUDI O
CODE C
1
CLRC MOS1
1
CPU_ FAN1
HDLED RESET
PLED PW RBTN
1
PANEL 1
CHA_ FAN1
SPEA KER1
1
HD_ AUDI O1
1
30.5cm (12.0-in)
22.4cm (8.8-in)
6
7
1
2
4
3
5
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
2627
28
29
32Mb
BIOS
IR1
1
PCIE 2
HDMI1
Top:
CTR BA SS
Cen ter :
REA R S PK
Bot tom :
Opt ica l
SPD IF
Top:
LIN E I N
Cen ter :
FRO NT
Bot tom :
MIC IN
1
USB6 _7
CPU _FAN2
A75 Pro4/MVP
ErP/E uP Ready
R oHS
DDR3 2400+
USB 3.0
T: USB 4
B: U SB5
CIR1
1
SATA3 6Gb/s
ATX1 2V1
HDMI 1.4a
Ps2
Key bo ard /
Mou se
SOCKET FM1
PCIE 4
Dr.
Debug
PWRB TN
RSTB TN
PLED 1
1
SATA3_ 1
SATA3_ 2
SATA3_ 3
SATA3_ 4
DDR3_A1 (64 bit, 2 4 0-pin module)
DDR3_A2 (64 bit, 240-pin module)
DDR3_B1 (64 bit, 240-pin module)
DDR3_B2 (64 bit, 240-pin module)
PWR _FAN1
FRON T_13 94
1
1
HDMI _SPDI F1
1
USB8 _9
1
USB1 0_11
VGA1
DVI_ CO N1
Clr CM O S
USB 2. 0
T: USB2
B: US B3
IEE E 1 394
eSATA1
Top:
RJ-45
USB 3. 0
T: U SB 0
B: USB1
CHA _FAN3
CHA _FAN2
USB 3.0
1394a
303132
33
34
35
36
37
38
39
40
41
42
PCIE 3
PCI2
PCI3
SATA3_ 5
DX11
X Fast USB
Desi gn ed i n Ta ip ei
Dual Graphics

ASROCK A75 Pro4/MVP Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	800, 1066, 1333, 1600, 1866, 2400 MHz
Processor socket	Socket FM1
Processor manufacturer	AMD
Compatible processor series	AMD E
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA III connectors	5
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
USB 2.0 ports quantity	2
Certification	FCC, CE, WHQL
Component for	PC
Motherboard chipset	AMD A75
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 10
Supported storage drive interfaces	SATA III
DirectX version	11
Maximum resolution	2560 x 1600 pixels
Maximum graphics card memory	512 MB
Parallel processing technology support	2-Way CrossFireX, Quad-GPU CrossFireX
PCI Express slots version	2.0
LAN controller	Realtek RTL8111E
Networking features	Gigabit Ethernet
BIOS type	AMI
ACPI version	1.1
BIOS memory size	32 Mbit

Weight and Dimensions

Depth	224 mm
Width	205 mm
