11
1.3 Motherboard Layout
   
   
   
   
   
   
   
   
   
   
   
   
   
   
   
 
Super
I/O
CM OS
BA TT ERY
ATXPWR1
AMD
A75 FCH
(Hudson-D3)
Chipset
COM 1
PCIE1
PCI1
LAN
AUD IO
COD EC
1
CLR CM OS1
1
CPU _FA N1
HDLE D R ESET
PLED P WRBT N
1
PANEL 1
CHA _FA N1
SPE AKE R1
1
HD_ AUDI O1
1
22.6cm (8.9-in)
21.6cm (8.5-in)
6
7
1
2 4
3
5
8
9
10
11
12
13
14
15
16
17
181920
2122
23
24
25
26
27
28
29
32Mb
BIOS
IR1
1
PCIE2
FSB800
DDR3_A1 (6 4 bit, 240-pin mod ule)
DDR3_B1 (6 4 bit, 240-pin mod ule)
SATA_ 2
HDMI1
Top:
LIN E IN
Cen ter :
FRO NT
Bot tom :
MIC I N
RJ-4 5 LAN
1
1
1
USB 6_7
USB 8_9
USB 10_ 11
PWR _FAN1
A75M-HVS
ErP/EuP Ready
Designed in Taipei
RoHS
DDR3 2400+
DX11
USB 2 .0
T: USB0
B: USB1
CIR1
1
SOCKET FM1
SATA_ 1
SATA_ 4
SATA_ 3
1
LP T 1
ATX1 2V1
HDMI 1.4a
PS2
Mouse
PS2
Keyboa rd
VGA1
USB 3.0
T: USB2
B: USB3
30
SATA_ 6
SATA_ 5
USB 3.0
T: USB4
B: USB5
Dual Graphics
X
Fast USB
SATA3 6Gb/s
USB 3.0

Table of Contents

Other manuals for ASROCK A75M-HVS

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK A75M-HVS and is the answer not in the manual?

ASROCK A75M-HVS Specifications

General IconGeneral
Memory channelsDual-channel
Number of memory slots2
Maximum internal memory16 GB
Supported memory clock speeds800, 1066, 1333, 1600, 1866, 2400 MHz
Processor socketSocket FM1
Processor manufacturerAMD
USB 2.0 connectors3
Power fan connectorYes
Number of COM connectors1
Number of SATA III connectors6
Number of Parallel ATA connectors0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
CertificationFCC, CE, WHQL
Component forPC
Power source typeATX
Motherboard chipsetAMD Hudson D3
Audio output channels5.1 channels
Motherboard form factormicro ATX
Compatible operating systemsWindows XP, Vista, 7
Parallel processing technology supportNot supported
LAN controllerRealtek RTL8111E
BIOS typeAMI
ACPI version1.1
Weight and Dimensions IconWeight and Dimensions
Depth216 mm
Width226 mm
