ASROCK AB350 Gaming-ITX/ac User Manual

Fatal1ty AB350 Gaming-ITX/ac Series
3
English
* Actual support may vary by CPU
•
DirectX 12, Pixel Shader 5.0
•
Max. shared memory 2GB
•
Supports 2 x HDMI with max. resolution up to 4K x 2K
(4096x2160) @ 24Hz / (3840x2160) @ 30Hz
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI Ports (Compliant
HDMI monitor is required)
•
Supports HDCP with HDMI Ports
•
Supports Full HD 1080p Blu-ray (BD) playback with HDMI
Ports
Audio
•
7.1 CH HD Audio with Content Protection (Realtek ALC1220
Audio Codec)
•
Premium Blu-ray Audio support
•
Supports Surge Protection
•
Nichicon Fine Gold Series Audio Caps
•
120dB SNR DAC with Dierential Amplier
•
Pure Power-In
•
Direct Drive Technology
•
PCB Isolate Shielding
•
Impedance Sensing on Line Out port
•
Individual PCB Layers for R/L Audio Channel
•
Gold Audio Jacks
•
Supports Creative SoundBlaster Cinema3
LAN
•
Gigabit LAN 10/100/1000 Mb/s
•
GigaLAN Intel® I211AT
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Wireless
LAN
•
Supports IEEE 802.11a/b/g/n/ac
•
Supports Dual-Band (2.4/5 GHz)
•
Supports high speed wireless connections up to 433Mbps
•
Supports Bluetooth 4.0 / 3.0 + High speed class II

ASROCK AB350 Gaming-ITX/ac Specifications

General

Form Factor	Mini ITX
Chipset	AMD B350
Socket	AM4
Maximum Memory	32GB
Memory Speed	DDR4 3200+(OC)
SATA Ports	4 x SATA3 6.0 Gb/s
Audio Chipset	Realtek ALC1220
HDMI	1
DisplayPort	1
RAID Support	RAID 0, 1, 10
Memory Slots	2
PCI Express x16 Slots	1
M.2 Slots	1 x M.2 Socket (Key M), supports type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)
Wireless	802.11ac WiFi
Bluetooth	Bluetooth 4.2
Onboard Ethernet	1 x Gigabit LAN
Audio Ports	5
USB Ports	6 x USB 3.1 Gen1 (2 Front, 4 Rear)
