ASROCK AB350 Gaming-ITX/ac User Manual

English
2
1.2 Specications
Platform
•
Mini-ITX Form Factor
•
2oz Copper PCB
CPU
•
Supports AMD Socket AM4 A-Series APUs (Bristol Ridge)
and Ryzen Series CPUs (Summit Ridge)
•
Digi Power design
•
8 Power Phase design
•
Supports 95W Water Cooling
Chipset
•
AMD Promontory B350
Memory
•
Dual Channel DDR4 Memory Technology
•
2 x DDR4 DIMM Slots
•
AMD Ryzen series CPUs support DDR4 3200+(OC)/2933
(OC)/2667/2400/2133 ECC & non-ECC, un-buered memo-
ry*
•
AMD 7
th
Gen A-Series APUs support DDR4 2400/2133 ECC
& non-ECC, un-buered memory*
* Please refer to Memory Support List on ASRock’s website for
more information. (http://www.asrock.com/)
* Please refer to page 25 for DDR4 UDIMM maximum frequency
support.
•
Max. capacity of system memory: 32GB
•
15μ Gold Contact in DIMM Slots
Expansion
Slot
AMD Ryzen series CPUs
•
1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)*
AMD 7
th
A-Series APUs
•
1 x PCI Express 3.0 x16 Slot (PCIE1: x8 mode)*
* Supports NVMe SSD as boot disks
•
1 x Vertical M.2 Socket (Key E) with the bundled WiFi-
802.11ac module (on the rear I/O)
•
15μ Gold Contact in VGA PCIe Slot (PCIE1)
Graphics
•
Integrated AMD Radeon
TM
R-Series Graphics in A-series
APU*

ASROCK AB350 Gaming-ITX/ac Specifications

General

Form Factor	Mini ITX
Chipset	AMD B350
Socket	AM4
Maximum Memory	32GB
Memory Speed	DDR4 3200+(OC)
SATA Ports	4 x SATA3 6.0 Gb/s
Audio Chipset	Realtek ALC1220
HDMI	1
DisplayPort	1
RAID Support	RAID 0, 1, 10
Memory Slots	2
PCI Express x16 Slots	1
M.2 Slots	1 x M.2 Socket (Key M), supports type 2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)
Wireless	802.11ac WiFi
Bluetooth	Bluetooth 4.2
Onboard Ethernet	1 x Gigabit LAN
Audio Ports	5
USB Ports	6 x USB 3.1 Gen1 (2 Front, 4 Rear)
