ASROCK AB350M PRO4/DASH User Manual

AB350M Pro4/DASH
3
English
Expansion
Slot
AMD Ryzen series CPUs (Summit Ridge and Pinnacle Ridge)
•
1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*
•
1 x PCI Express 2.0 x16 Slot (PCIE4: x4 mode)
AMD 7
th
A-Series APUs
•
1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode)*
•
1 x PCI Express 2.0 x16 Slot (PCIE4: x4 mode)
AMD Ryzen series CPUs (Raven Ridge)
•
1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode) (If you use
Athlon 2xxGE series APU, PCIE2 slot will run at x4 mode.)*
•
1 x PCI Express 2.0 x16 Slot (PCIE4: x4 mode)
* Supports NVMe SSD as boot disks
•
2 x PCI Express 2.0 x1 Slots
•
Supports AMD Quad CrossFireX
TM
and CrossFireX
TM
•
1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module
Graphics
•
Integrated AMD Radeon
TM
Vega Series Graphics in Ryzen
Series APU*
•
Integrated AMD Radeon
TM
R-Series Graphics in A-series
APU*
* Actual support may vary by CPU
•
DirectX 12, Pixel Shader 5.0
•
Shared memory default 2GB. Max Shared memory supports
up to 16GB.
* e Max shared memory 16GB requires 32GB system memory
installed.
•
ree graphics output options: D-Sub, HDMI and
DisplayPort 1.2
•
Supports Triple Monitor
•
Supports HDMI with max. resolution up to 4K x 2K
(4096x2160) @ 24Hz / (3840x2160) @ 30Hz
•
Supports DisplayPort 1.2 with max. resolution up to 4K x 2K
(4096x2160) @ 60Hz
•
Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI Port (Compliant
HDMI monitor is required)
•
Supports HDCP with HDMI and DisplayPort 1.2 Ports
•
Supports Full HD 1080p Blu-ray (BD) playback with HDMI
and DisplayPort 1.2 Ports

ASROCK AB350M PRO4/DASH Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD A
Maximum number of SMP processors	1
Certification	FCC, CE, WHQL, ErP/EuP
Component for	PC
Power source type	ATX
Motherboard chipset	AMD B350
PC health monitoring	CPU, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64
ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2933, 3200 MHz
RAID levels	0, 1, 10
Supported storage drive interfaces	SATA III
Parallel processing technology support	Quad-GPU CrossFireX
USB 2.0 connectors	2
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
BIOS type	UEFI
ACPI version	5.1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	-
LAN controller	Realtek RTL8111EPV, Realtek 8111EP
Ethernet interface type	Gigabit Ethernet
Cables included	SATA

Weight and Dimensions

Width	- mm
